Product description

Cable labels with protective laminate use a special laminate film that is extremely flexible and conformable. Even with small cable diameters, this reliably prevents the marker from standing up.

The marking is optimally protected from environmental influences and mechanical stress by the overlamination. For larger cable diameters, the excess laminate film can be separated from the label at the perforation point. The advantage of this technology is that it allows a very large number of cross-sections to be covered with one marker size.

For an optimal printing result, we recommend the use of a Texit thermal transfer printer and the matching ribbon.

For Texit cable labels with protective laminate, you can request sample products free of charge and without obligation.

Size chart & item designations

Article description Article number Size Colour au_en_cable_average gr__e_font marker_per_row vpe_per_packaging
KRT2-P0-013x025/06-WE 20907 W 13mm x H 25mm x S 6mm white 2-5mm 13.00 mm wide x 6.00 mm high 6 15.000
KRT2-P0-018x035/09-WE 20409 W 18mm x H 35mm x S 9mm white 4-7mm 18.00 mm wide x 9.00 mm high 5 9.000
KRT2-P0-023x034/14-WE 20398 W 23mm x H 34mm x S 14mm white 4-7mm 23.00 mm wide x 14.00 mm high 4 12.500
KRT2-P0-023x040/10-WE 20981 W 23mm x H 40mm x S 10mm white 4-7mm 23.00 mm wide x 10.00 mm high 4 6.000
KRT2-P0-023x051/13-WE 20289 W 23mm x H 51mm x S 13mm white 4-12mm 23.00 mm wide x 13.00 mm high 4 5.000
KRT2-P0-023x073/18-WE 20206 W 23mm x H 73mm x S 18mm white 4-17mm 23.00 mm wide x 18.00 mm high 4 4.000
KRT2-P0-032x073/15-WE 21408 W 32mm x H 73mm x S 18mm white 4-17mm 32.00 mm wide x 15.00 mm high 3 3.000
KRT2-P0-032x098/26-WE 20710 W 32mm x H 98mm x S 26mm white 4-23mm 32.00 mm wide x 26.00 mm high 3 2.000
KRT2-P0-032x150/30-WE 20483 W 32mm x H 150mm x S 30mm white 4-37mm 32.00 mm wide x 30.00 mm high 3 2.000
Enlarge table
Article description Article number Size Colour au_en_cable_average gr__e_font marker_per_row vpe_per_packaging
KRT2-P0-013x025/06-WE 20907 W 13mm x H 25mm x S 6mm white 2-5mm 13.00 mm wide x 6.00 mm high 6 15.000
KRT2-P0-018x035/09-WE 20409 W 18mm x H 35mm x S 9mm white 4-7mm 18.00 mm wide x 9.00 mm high 5 9.000
KRT2-P0-023x034/14-WE 20398 W 23mm x H 34mm x S 14mm white 4-7mm 23.00 mm wide x 14.00 mm high 4 12.500
KRT2-P0-023x040/10-WE 20981 W 23mm x H 40mm x S 10mm white 4-7mm 23.00 mm wide x 10.00 mm high 4 6.000
KRT2-P0-023x051/13-WE 20289 W 23mm x H 51mm x S 13mm white 4-12mm 23.00 mm wide x 13.00 mm high 4 5.000
KRT2-P0-023x073/18-WE 20206 W 23mm x H 73mm x S 18mm white 4-17mm 23.00 mm wide x 18.00 mm high 4 4.000
KRT2-P0-032x073/15-WE 21408 W 32mm x H 73mm x S 18mm white 4-17mm 32.00 mm wide x 15.00 mm high 3 3.000
KRT2-P0-032x098/26-WE 20710 W 32mm x H 98mm x S 26mm white 4-23mm 32.00 mm wide x 26.00 mm high 3 2.000
KRT2-P0-032x150/30-WE 20483 W 32mm x H 150mm x S 30mm white 4-37mm 32.00 mm wide x 30.00 mm high 3 2.000

Also available with custom printing ⬇️

Save investment costs & order directly with your desired print? That's what the Texit printing service is for

To the printing service

Cable labels with protective laminate (KRT2-P0)
Cable labels with Protective laminate (KRT2-P0)

:

:

:

:

:

Your contact

Drazen Milosevic +49 (0) 6071 928 4023
Product ADVICE REQUEST
Packaging units: 15.000
Colour: White
Other colors available upon request.
3-5 working days standard delivery
Prices on request.

Product description

Cable labels with protective laminate use a special laminate film that is extremely flexible and conformable. Even with small cable diameters, this reliably prevents the marker from standing up.

The marking is optimally protected from environmental influences and mechanical stress by the overlamination. For larger cable diameters, the excess laminate film can be separated from the label at the perforation point. The advantage of this technology is that it allows a very large number of cross-sections to be covered with one marker size.

For an optimal printing result, we recommend the use of a Texit thermal transfer printer and the matching ribbon.

For Texit cable labels with protective laminate, you can request sample products free of charge and without obligation.

Size chart & item designations

Article description Article number Size Colour au_en_cable_average gr__e_font marker_per_row vpe_per_packaging
KRT2-P0-013x025/06-WE 20907 W 13mm x H 25mm x S 6mm white 2-5mm 13.00 mm wide x 6.00 mm high 6 15.000
KRT2-P0-018x035/09-WE 20409 W 18mm x H 35mm x S 9mm white 4-7mm 18.00 mm wide x 9.00 mm high 5 9.000
KRT2-P0-023x034/14-WE 20398 W 23mm x H 34mm x S 14mm white 4-7mm 23.00 mm wide x 14.00 mm high 4 12.500
KRT2-P0-023x040/10-WE 20981 W 23mm x H 40mm x S 10mm white 4-7mm 23.00 mm wide x 10.00 mm high 4 6.000
KRT2-P0-023x051/13-WE 20289 W 23mm x H 51mm x S 13mm white 4-12mm 23.00 mm wide x 13.00 mm high 4 5.000
KRT2-P0-023x073/18-WE 20206 W 23mm x H 73mm x S 18mm white 4-17mm 23.00 mm wide x 18.00 mm high 4 4.000
KRT2-P0-032x073/15-WE 21408 W 32mm x H 73mm x S 18mm white 4-17mm 32.00 mm wide x 15.00 mm high 3 3.000
KRT2-P0-032x098/26-WE 20710 W 32mm x H 98mm x S 26mm white 4-23mm 32.00 mm wide x 26.00 mm high 3 2.000
KRT2-P0-032x150/30-WE 20483 W 32mm x H 150mm x S 30mm white 4-37mm 32.00 mm wide x 30.00 mm high 3 2.000
Enlarge table
Article description Article number Size Colour au_en_cable_average gr__e_font marker_per_row vpe_per_packaging
KRT2-P0-013x025/06-WE 20907 W 13mm x H 25mm x S 6mm white 2-5mm 13.00 mm wide x 6.00 mm high 6 15.000
KRT2-P0-018x035/09-WE 20409 W 18mm x H 35mm x S 9mm white 4-7mm 18.00 mm wide x 9.00 mm high 5 9.000
KRT2-P0-023x034/14-WE 20398 W 23mm x H 34mm x S 14mm white 4-7mm 23.00 mm wide x 14.00 mm high 4 12.500
KRT2-P0-023x040/10-WE 20981 W 23mm x H 40mm x S 10mm white 4-7mm 23.00 mm wide x 10.00 mm high 4 6.000
KRT2-P0-023x051/13-WE 20289 W 23mm x H 51mm x S 13mm white 4-12mm 23.00 mm wide x 13.00 mm high 4 5.000
KRT2-P0-023x073/18-WE 20206 W 23mm x H 73mm x S 18mm white 4-17mm 23.00 mm wide x 18.00 mm high 4 4.000
KRT2-P0-032x073/15-WE 21408 W 32mm x H 73mm x S 18mm white 4-17mm 32.00 mm wide x 15.00 mm high 3 3.000
KRT2-P0-032x098/26-WE 20710 W 32mm x H 98mm x S 26mm white 4-23mm 32.00 mm wide x 26.00 mm high 3 2.000
KRT2-P0-032x150/30-WE 20483 W 32mm x H 150mm x S 30mm white 4-37mm 32.00 mm wide x 30.00 mm high 3 2.000

Also available with custom printing ⬇️

Save investment costs & order directly with your desired print? That's what the Texit printing service is for

To the printing service
20907, 20409, 20398, 20981, 20289, 20206, 21408, 20710, 20483,

What our customers say:

Cable labels with protective laminate Features

In the case of cable labels with protective laminate, the upper material of the labels has a protective laminate layer. The cable labels already provided with permanent acrylate adhesive are made of high-quality, halogen-free polyolefin plastic and can be used at temperatures from -20 up to +80 degrees Celsius.

Thanks to the protective laminate, the self-laminating labels have a long shelf life and are resistant to UV rays as well as oils, grease, moisture, cleaning agents and conventional chemicals. The KRT2-P0 cable labels with protective laminate are therefore also suitable for outdoor use or in other areas where the label is exposed to heavy loads. These products are supplied on a roll.

Material of cable labels with protective laminate

The KRT2-P0 labels from Texit are made of highly flexible and conformable polyolefin plastic and are already provided with adhesive and laminate film. These cable labels are halogen-free and can therefore also be used in areas where no toxic gases may be generated (e.g. application in railroad technology). Thanks to the high UV resistance, the cable labels with laminate film can also be used for marking cables outdoors. The adhesive is a permanent, transparent acrylic adhesive. This ensures that the labels adhere well to smooth and uneven surfaces of cables and wires.

Size and colors

In our standard range, the cable labels with laminate film are available in the color white. Thanks to the extremely flexible material, the labels are particularly suitable for small cable diameters. They are already available from a width of 13mm and with a labeling field of 6mm. With our standard range we cover the most common cable diameters.

Do you need other sizes or colors? Then just send us a request with the desired data and we will make you an individual offer. The delivery of custom-made products is associated with a longer delivery time, because the material must be specially made. You can find more information about this on our service page.

Print cable labels with protective laminate

The KRT2-P0 labels can be printed quickly and easily with our TX4M/300 thermal transfer printer. In addition to the label printer, you also need the matching ribbon for printing. Hereby we guarantee our customers a high quality of the labeling. The KRT2-P0 labels are additionally protected by a protective laminate after printing.

Do you have any questions about printing or the article itself? Please send us an inquiry about the cable labels with protective laminate via the contact form. Our team will record your data immediately and will be happy to advise you on our product range without obligation. At Texit, we make cable marking with laminate label easy.
